Compatible with
TOYOTA AYGO (_B4_)
,
CITROËN C1 II (PA_, PS_)
,
PEUGEOT 108
Show more info
266.73 EUR
inc. VAT 21%
In stock 2
No description found
Drive pulley-Ø [mm]
+110
Displacement-Compressor [ccm]
83
Compressor ID
DKV09Z
Compressor oil
PAG 46 YF
Plug connector housing shape
rectangular
Additional article/Additional info 2
with PAG compressor oil
Sleeve diameter [mm]
20,7
Outlet diameter [mm]
14,4
Number of grooves
6
Number of pin contacts
2
Oil fill quantity [ml]
+130
Type of connector
Connector plug
Coolant
R 134a
Coolant
R 1234yf
Voltage [V]
1/2"
Additional article/Additional info 2
with electromagnetic clutch
Additional article/Additional info 2
with diode
-
TOYOTA
-
AYGO (_B4_)
- 1.0 (KGB40) (51kW/69PS)
- 1.2 (PAB40) (60kW/82PS)
- 1.0 VVTi (KGB40) (53kW/72PS)
-
AYGO (_B4_)
-
CITROËN
-
C1 II (PA_, PS_)
- 1.0 VTi 68 (51kW/69PS)
- 1.0 VTi 72 (53kW/72PS)
-
C1 II (PA_, PS_)
-
PEUGEOT
-
108
- 1.0 VTi (51kW/69PS)
- 1.0 VTi 72 (53kW/72PS)
-
108
